Small Pure Sine Wave Inverter LED Display
Product Overview
Small Pure Sine Wave Inverter is an efficient and reliable small power conversion device that can stably convert DC into standard sinusoidal AC. The output waveform is pure and has no electromagnetic pollution. It can provide stable power support for various electrical equipment.
The product adopts advanced control technology, has an ultra-wide voltage adaptability range, can operate stably in complex power environments, and cooperates with the fully automatic voltage stabilization function to ensure stable output voltage. It has built-in overload, short circuit, overvoltage, undervoltage, overtemperature and other multiple protection mechanisms to ensure equipment safety in all aspects.
It is equipped with a simple LED display to display the working status in real time. Some models can be upgraded to a digital LCD display to present more operating data. The power supply time can be flexibly configured to adapt to different usage scenarios.
Whether it is home emergency power supply, power supply for vehicle-mounted electronic equipment, or outdoor camping, field work and other scenarios, the Small Pure Sine Wave Inverter can provide reliable power supply to meet diverse power needs.
Technical Parameters
| Specification | 300W | 500W | 1000W | 1500W | 2000W | 2500W | 2000W | |
| Input | Input voltage | 12/24/48VDC | ||||||
| 12VDC | 10~15.5VDC | |||||||
| 24V DC | 20~31VDC | |||||||
| 48V DC | 40~62VDC | |||||||
| Efficiency | >90% | |||||||
| Output | Output voltage | 100/110/120VAC or 220/230/240VAC | ||||||
| Rated power | 300W | 500W | 1000W | 1500W | 3000W | 2500W | 3000W | |
| Instant power | 600W | 1000W | 2000W | 3000W | 4000W | 5000W | 6000W | |
| Output waveform | Pure sine wave | |||||||
| Output frequency | 50Hz or 60Hz | |||||||
| USB output | 5V,1A | |||||||
| Wave form | ≤3% | |||||||
| Operating temperature | -10℃~+50℃ | |||||||
| Humidity | 20%~90%RH | |||||||
| Storage temperature | -30℃~+70℃ | |||||||
| Machine size (mm) | 212*142*65 | 242*142*65 | 318*189*81 | 343*189*81 | 371*235*97 | 405*235*97 | 426*235*97 | |
| Net weight (kg) | 0.8 | 1.0 | 2.1 | 2.3 | 3.7 | 4.5 | 5.1 | |
| Gross weight (kg) | 1.0 | 1.2 | 2.5 | 3 | 4.5 | 5.3 | 6.1 | |
| Inner box size (mm) | 275*160*115 | 295*160*115 | 400*230*150 | 440*230*140 | 490*290*180 | 490*290*180 | 490*290*165 | |
| Packing quantity (only) | 10 | 10 | 4 | 4 | 2 | 2 | 2 | |
| Weight (kg) | 11.05 | 12.76 | 10.87 | 12.72 | 9.53 | 11.21 | 12.81 | |
| Packing size (mm) | 620*290*350 | 630*310*350 | 480*430*310 | 480*450*310 | 510*310*380 | 510*310*380 | 510*310*380 | |
| Packing volume (m³) | 0.0629 | 0.0684 | 0.0640 | 0.0670 | 0.0601 | 0.0601 | 0.0601 | |
Protection
Customized sockets
